Mizar Village (Climbing Wall)

Certified according to European Standard EN 1176 by the German Institute TÜV - SÜD.
Made of hot-dip galvanized and powder-coated steel with pantographed HDPE panels with rounded edges.
Composed of n. 1 tower with circular-section galvanized steel posts Ø 89 mm, platform with galvanized steel tubular frame and 30/10 chequered aluminum flooring, decorative polyethylene roof with steel tubular connections, and protective HDPE panels, size cm 100x100x355h, and n. 1 tower with Ø 89 mm galvanized steel posts, platform with galvanized steel frame and 30/10 chequered aluminum flooring, protective HDPE panels and polyethylene seat, size cm 100x100x248h.
Includes n. 1 polyethylene climbing wall with handholds made of colored polyester resin and quartz composite, n. 1 horizontal bridge with Ø 50 mm tubular steel handrail, side rails in reinforced rope and HDPE walking panels mounted on galvanized tubular supports, n. 1 spider web in reinforced rope on a Ø 50 mm tubular frame with colored nylon rope stops, n. 1 slide h. 150 cm made of high-density rotational molded polyethylene with pantographed HDPE side panels.
Also includes n. 2 manipulative play panels in HDPE: Time Game and Maze Game.
The play panels are sensory, accessible, and usable also by children with disabilities.
Assembled using galvanized 8.8 steel bolts and self-locking nuts.
Colored nylon safety bolt covers compliant with regulations. Post caps in polyethylene.
Powder coating at 180°C with UV- and weather-resistant polyester powder.
Ground anchoring with hot-dip galvanized steel brackets.

Available in the following versions:

• Type A (TO PLOUGH IN) with hot-dip galvanized steel anchors;
• Type B (TO FIX ON THE FLOOR), with hot-dip galvanized steel brackets for fixing using "FISHER" type anchors or similar, NOT SUPPLIED.

Supplied in an assembly-kit.

• Overall Dimensions Max: cm 557x535x355h
• Fall Height: cm 185
• Age: years 3-12
• Assembly Time: h 8
• Number of users: 11
• Minimum Space: cm 850x925
• Impact Area: m² 53,00
